1.5kw-3kw High Speed Permanent Magnet Brushless Motor Generator

high speed generator motor  , turbine generator motor  , industrial compressors motor  , oil and gas compressors motor  , HVAC compressors motor  , laser and fuel cell cooling systems Rail transit  , papermaking motor  , sewage treatment motor  , pharmaceuticals motor  , evaporation and crystallization motor  , waste heat power generation  , new energy vehicles motor  , turbine steam turbines generator  , gas turbines generation  , ORC generator system
Inquiry Send Email

Description

The motor speed, voltage, power can be customized according to the requirements, but its better to be no more than 15, 000 speed. The motor can be made as wind cooling or water cooling, AC or DC. The front cover of the motor could have flange front edge, the size and the output shaft can also be customized.
power Voltage speed Rated torque Peak torque Peak power current Current peak Efficiency weight
1.5kw 220V 18000 0.79 1.5 2.2 4.3 8 92.5% 6kg
2 kw 220V 20000 0.95 2 3 5.7 10 92.5% 7kg
3 kw 220V 30000 0.95 2 4.5 8.6 16 92.5% 8kg
1.5kw-3kw High Speed Permanent Magnet Brushless Motor Generator
