Description
The motor speed, voltage, power can be customized according to the requirements, but its better to be no more than 15, 000 speed. The motor can be made as wind cooling or water cooling, AC or DC. The front cover of the motor could have flange front edge, the size and the output shaft can also be customized.
Brushless structure, no spark and electromagnetic interference. Protection level: IP44. Work: Continuous S1, Insulation class: H level.
(3)Good load characteristics, good low speed performance, high startup torque, small startup current, saving energy.
(4)Brushless structure brings high reliability and better protection, suitable for dust circumstance.
(5)In the speed range motor can operate efficiently, improving very much compared with brush DC motors and asynchronous motors (only having high efficiency around rated points), the cost could be taken back in 1 year by saving energy.
(6)Motor using plug-in rare earth magnet steels, especially suitable for turbulence, repeated start, and the ways to transport.
(7)Imported oil-contain bearing, maintenance free and high reliability. The motor shaft can be made into the spline connection.
(8)Motor drive has soft startup and soft stop function. Have overvoltage, over-current, short-circuit, phase, overload protection, etc. System can display voltage, current, temperature, speed or other motor parameters. The motor with temperature sensors can change its output power according to the motor temperature to make sure the reliability of the motor and the system.
Brushless structure, no spark and electromagnetic interference. Protection level: IP44. Work: Continuous S1, Insulation class: H level.
(3)Good load characteristics, good low speed performance, high startup torque, small startup current, saving energy.
(4)Brushless structure brings high reliability and better protection, suitable for dust circumstance.
(5)In the speed range motor can operate efficiently, improving very much compared with brush DC motors and asynchronous motors (only having high efficiency around rated points), the cost could be taken back in 1 year by saving energy.
(6)Motor using plug-in rare earth magnet steels, especially suitable for turbulence, repeated start, and the ways to transport.
(7)Imported oil-contain bearing, maintenance free and high reliability. The motor shaft can be made into the spline connection.
(8)Motor drive has soft startup and soft stop function. Have overvoltage, over-current, short-circuit, phase, overload protection, etc. System can display voltage, current, temperature, speed or other motor parameters. The motor with temperature sensors can change its output power according to the motor temperature to make sure the reliability of the motor and the system.
| power | voltage | speed | Rated torque | Peak torque | Peak power | current | Current peak | Efficiency | weight | Chassis size |
| 120kw | 380V | 6000 | 191Nm | 300Nm | 150KW | 192A | 260A | 96.1% | 240kg | Y200-230 |
| 200kw | 380V | 10000 | 187Nm | 300Nm | 300KW | 320A | 450A | 96.2% | 220kg | Y200-210 |
