Description
We offer various kinds of permanent magnetic generator from 0.1KW-1500KW(vertical and horizontal), please contact us for more detail informations.
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
| Rated power | Voltage | Rated Speed | Frequency | Rated torque | Currency | Efficiency |
| 500 kw | 400V | 250rpm | 50Hz | 19100Nm | 776A | 93.7% |
| 550 kw | 400V | 250rpm | 50Hz | 21000Nm | 860A | 93.7% |
| 800kw | 400V | 400rpm | 50Hz | 19500Nm | 1260A | 95.5% |
