Description
We offer various kinds of permanent magnetic generator from 0.1KW-1500KW(vertical and horizontal), please contact us for more detail informations.
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
| Description | Power | Speed | Voltage | Rated torque | Insult | Curent | Weight |
| Low speed direct drive permanent magnet generator | 220kw | 200rpm | 690V | 10510Nm | H | 184A | 2600kg |
| 300kw | 200rpm | 690V | 14330Nm | H | 251A | 2800kg | |
| 60kw | 60rpm | 400V | 9550Nm | H | 87A | 2500kg |
