Description
We offer various kinds of permanent magnetic generator from 0.1KW-1500KW(vertical and horizontal), speed from 30rpm-6000rpm, output voltage and speed can customize according your request
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
Features of Permanent Magnet Generator
*Low start up speed, Gearless, low RPM generator
*High standard components for use in hard and extreme
Environments for wind turbine
*High efficiency low mechanical resistance energy loss
*Design for reliable long operational lifetime
| Power(KW) | AC voltage(V) | speed(RPM) | Rated torque(NM) | Start torque(NM) | current(A) | efficiency | weight |
| 15 | 230 | 150 | 955.0 | 19.1 | 40.5 | 93.80% | 400 |
| 25 | 230 | 200 | 1193.8 | 23.9 | 67.5 | 93.80% | 410 |
| 35 | 400 | 300 | 1114.2 | 22.3 | 54.3 | 93.80% | 400 |
| 50 | 400 | 450 | 1061.1 | 21.2 | 77.6 | 93.80% | 400 |
