Description
YSQ2 is the newest product developed by our company special for mines, whose mounting dimension is as same as the old series JS11-15#, and whose power level, mounting dimension and electric performance meet GB755 Basic Technical Requirements for Rotating Motor. It is used to drive coal mill, rolling mill, winch, crusher and other machineries in mines. It is a new series developed by combining a large amount of introduced technologies and our decades of experiences in design and manufacturing of motors for mines.
Possessing a lot of advantages, including compact structure, slighter vibration and lower noise, high reliability, strong overload capacity and installation & maintenance convenience, the Series YSQ2 is a new generation of motor special for mines with high-performance.
By adopting a box-type structure and the integrated welded frame made of steel plate, the series has a good rigidity and a good shock resistance as well as a light weight. Ventilation pattern: natural air cooling, i.e. IC01; protection class: IP23; rated frequency: 50HZ; voltage classes: 380V, 3KV, 6KV, 10KV. And we can design and customize motors with other rated voltage or frequency values (415V, 690V, 3KV, 10KV, 60HZ), high protection class: IP44, IP54 and to be used in special environment (high attitude, humid tropics, strong corrosion) as required by customers.
Possessing a lot of advantages, including compact structure, slighter vibration and lower noise, high reliability, strong overload capacity and installation & maintenance convenience, the Series YSQ2 is a new generation of motor special for mines with high-performance.
By adopting a box-type structure and the integrated welded frame made of steel plate, the series has a good rigidity and a good shock resistance as well as a light weight. Ventilation pattern: natural air cooling, i.e. IC01; protection class: IP23; rated frequency: 50HZ; voltage classes: 380V, 3KV, 6KV, 10KV. And we can design and customize motors with other rated voltage or frequency values (415V, 690V, 3KV, 10KV, 60HZ), high protection class: IP44, IP54 and to be used in special environment (high attitude, humid tropics, strong corrosion) as required by customers.
|
YSQ2 Tech Data Sheet of 3-phase Asyn. Motor Series YSQ2 Special for Mines |
|||||||||
|
Model |
Power |
Voltage |
Current |
Efficiency |
Power factor |
Starting current |
Starting torque |
Max. torque |
|
| 3752-6 | 75 | 380 | 146 | 91.0 | 0.86 | 6.0 | 1.0 | 2.2 | |
| 3753-6 | 95 | 380 | 181 | 91.5 | 0.87 | 6.0 | 1.0 | 2.2 | |
| 3754-6 | 115 | 380 | 218 | 92.0 | 0.87 | 6.0 | 1.0 | 2.2 | |
| 3752-8 | 60 | 380 | 122 | 90.0 | 0.83 | 5.5 | 1.0 | 2.2 | |
| 3753-8 | 70 | 380 | 140 | 90.5 | 0.84 | 5.5 | 1.0 | 2.2 | |
| 3754-8 | 80 | 380 | 159 | 91.0 | 0.84 | 5.5 | 1.0 | 2.2 | |
| 3752-10 | 45 | 380 | 97 | 89.0 | 0.79 | 5.5 | 1.0 | 2.2 | |
| 3753-10 | 55 | 380 | 118 | 89.5 | 0.79 | 5.5 | 1.0 | 2.2 | |
| 3754-10 | 65 | 380 | 137 | 90.0 | 0.80 | 5.5 | 1.0 | 2.2 | |
| 4501-6 | 130 | 380 | 247 | 92.0 | 0.87 | 6.0 | 1.0 | 2.2 | |
| 4502-6 | 155 | 380 | 289 | 92.5 | 0.88 | 6.0 | 1.0 | 2.2 | |
| 4503-6 | 185 | 380 | 345 | 92.5 | 0.88 | 6.0 | 1.0 | 2.2 | |
| 4504-6 | 215 | 380 | 399 | 93.0 | 0.88 | 6.0 | 1.0 | 2.2 | |
| 4501-8 | 95 | 380 | 189 | 91.0 | 0.84 | 5.5 | 1.0 | 2.2 | |
| 4502-8 | 110 | 380 | 215 | 91.5 | 0.85 | 5.5 | 1.0 | 2.2 | |
| 4503-8 | 130 | 380 | 253 | 92.0 | 0.85 | 5.5 | 1.0 | 2.2 | |
| 4502-8 | 155 | 380 | 301 | 92.0 | 0.85 | ||||
