Description
The motor speed, voltage, power can be customized according to the requirements, but its better to be no more than 15, 000 speed. The highest speed we can do is 24000rpm, The motor can be made as wind cooling or water cooling, AC or DC. The front cover of the motor could have flange front edge, the size and the output shaft can also be customized.
| power | voltage | speed | Rated torque | Peak torque | Peak power | current | Current peak | Efficiency | weight | Chassis size |
| 160kw | 380V | 10000 | 150Nm | 260Nm | 230KW | 254A | 450A | 95.9% | 170kg | Y180-240 |
| 315 kw | 380V | 18000 | 167Nm | 240Nm | 450KW | 506A | 720A | 95.9% | 180kg | Y180-260 |
