Description
We also offer various kind of other small hydro turbine generator,jsut inform us your water head and flow
Axial flow tubine generator
Francis Turbine Generator
Pelton Turbine Generator
Inclined-jet hydro turbine generator
Cross flow water turbine generator
Tubular water turbine generator
Impulse type water generator
low speed Permanent Magnet Generator
INCLINE JET TURBINE
|
Power (kW) |
Water head (m) |
Flow Rate (m3/s) |
Speed (r/min) |
Diameter (mm) |
| 10KW | 30-40 | 0.0482-0.05 | 1000 | 200mm |
| 15KW | 40 | 0.05 | 1000 | 200mm |
| 20KW | 40-50 | 0.089 | 1000 | 250mm |
| 30KW | 45 | 0.101 | 1000 | 250mm |
| 40KW | 55 | 0.12 | 1000 | 250-300mm |
| 50KW | 60 | 0.127 | 1000 | 300 |
|
Power (kW) |
Water head (m) |
Flow Rate (m3/s) |
Speed (r/min) |
|
| 10KW | 3 | 0.514 | 750 | 40mm |
| 15KW | 4 | 0.69 | 1000 | 40mm |
| 20KW | 2.5 | 1.19 | 1000 | 60mm |
| 30KW | 3.3 | 1.2 | 1000 | 60mm |
| 40KW | 3.8 | 1.63 | 1000 | 60mm |
| 50KW | 3.2 | 2.65 | 1000 | 80mm |
|
Power (kW) |
Water head (m) |
Flow Rate (m3/s) |
Speed (r/min) |
|
| 10KW | 6 | 0.31 | 1000-1500 | 300mm |
| 15KW | 6-7 | 0.26 | 1000-1500 | 300mm |
| 20KW | 7 | 0.38 | 1000 | 400mm-500mm |
| 30KW | 7 | 0.65 | 1000 | 400-500mm |
| 40KW | 6.5 | 0.82 | 1000 | 500-600mm |
| 50KW | 7.5 | 1.11 | 1000 | 600-700mm |
TUBULAR TURBINE
|
Power (kW) |
Water head (m) |
Flow Rate (m3/s) |
Speed (r/min) |
Diameter |
| 10KW | 6 | 0.31 | 1000-1500 | 300mm |
| 15KW | 6-7 | 0.26 | 1000-1500 | 300mm |
| 20KW | 7 | 0.38 | 1000 | 400mm-500mm |
| 30KW | 7 | 0.65 | 1000 | 400-500mm |
| 40KW | 6.5 | 0.82 | 1000 | 500-600mm |
| 50KW | 7.5 | 1.11 | 1000 | 600-700mm |
|
Power (kW) |
Water head (m) |
Flow Rate (m 3 /s) |
Speed (r/min) |
Penstock pipe diameter(mm) |
| 10KW | 12 | 0.15 | 1000 | 350mm |
| 15KW | 22 | 0.1 | 1000 | 350mm |
| 20KW | 23 | 0.15 | 1000 | 400mm-500mm |
| 30KW | 30 | 0.18 | 1000 | 400-500mm |
| 40KW | 16 | 0.4 | 1000 | 500-600mm |
| 50KW | 18 | 0.5 | 1000 |
700mm |
