Description
This series of products are suitabl for excitation and
interconnection control of low-voltage generator of 800KW or below.
It has relatively high technology and quality . This product can run
stably. The main functions of this product produce excitation of low
- voltage water turbin -generator set, synchronization and
interconnection control, protection and calculation so as to meet
interconnection requirements of low voltage generator set well.
PARTICULAR INFO
I、MAIN PERFORMANCE AND CHARACTERISTICS ★ Controllable silicon or
rotation excitation component and interconnection control component
are integrated into one cabinet with a much compact structure; ★
Automatic / manual on-off functions; ★ Microcomputer automatic
synchronization device is used for interconnection (can choice
dimlight manual synchronization); ★ Over-current, under-voltage and
over - voltage protection, users can use microcomputer protection
device if it is needed; ★ Excitation part conforms to the
requirements of G 10585-89 : fundamental requirements of excitation
systems for medium and small synchronous machines; ★ Simple to
install and operate, convenience to maintain and run reliably.
II、DEMONSTRATION OF MODELS Product type Rectification Method
Protection Method Breaker far/near FKL-301 single-phase bridge
routine relay DW15 On-site FKL-303 single-phase bridge Microcomputer
protection DW17(ME) remote control FKL-305 rotation single-phase
bridge routine relay DW15 On-site FKL-307 Rotation single-phase
bridge Microcomputer protection DW17(ME) remote control
Instructions: If dry type excitation transformer is included, the
ones with a capability below 20KVA should be put in panel. III、ORDER
INFORMATION ◎、Generator model and parameter(include excitation
parameters) ◎、Other specific requirements
