Description
Structural features
The shaft is flat-keyed out of the optical axis, and there are many kinds of matching forms. It can be installed on the foot according to customer requirements.
Note: ZC is series excitation, ZT is separate excitation
The shaft is flat-keyed out of the optical axis, and there are many kinds of matching forms. It can be installed on the foot according to customer requirements.
Note: ZC is series excitation, ZT is separate excitation
Series excitation type:
|
Model
|
Rated power | Rated voltage | Rated current | Rated speed | Rated torque | Insultation | Protect | Working |
| （Kw） | (V) | (A) | (r/min) | (N.m) | ||||
| ZC1.5-36 | 1.5 | 36 | 55 | 2800 | 5.1 | F | IP20 | 60min |
| ZC1.5-48 | 1.5 | 48 | 42 | 2800 | 5.1 | F | IP20 | 60min |
| ZC2.2-36 | 2.2 | 36 | 76 | 2000 | 10.5 | F | IP20 | 60min |
| ZC2.2-36 | 2.2 | 36 | 76 | 2800 | 7.5 | F | IP20 | 60min |
| ZC2.2-48 | 2.2 | 48 | 57 | 1500 | 14 | F | IP20 | 60min |
| ZC2.2-48 | 2.2 | 48 | 57 | 2000 | 10.5 | F | IP20 | 60min |
| ZC2.2-48 | 2.2 | 48 | 57 | 2500 | 8.4 | F | IP20 | 60min |
| ZC2.2-48 | 2.2 | 48 | 57 | 2800 | 7.5 | F | IP20 | 60min |
| ZC2.2-60 | 2.2 | 60 | 46 | 3300 | 6.4 | F | IP20 | 60min |
| ZC3-36 | 3 | 36 | 104 | 1500 | 19 | F | IP20 | 60min |
| ZC3-36 | 3 | 36 | 104 | 2000 | 14.3 | F | IP20 | 60min |
| ZC3-36 | 3 | 36 | 104 | 2800 | 10.2 | F | IP20 | 60min |
| ZC3-48 | 3 | 48 | 78 | 1500 | 19.1 | F | IP20 | 60min |
| ZC3-48 | 3 | 48 | 78 | 2000 | 14.33 | F | IP20 | 60min |
| ZC3-48 | 3 | 48 | 78 | 2500 | 11.5 | F | IP20 | 60min |
| ZC3-48 | 3 | 48 | 78 | 2800 | 10.2 | F | IP20 | 60min |
| ZC3-48 | 3 | 48 | 78 | 3200 | 9 | F | IP20 | 60min |
| ZC3-48 | 3 | 48 | 78 | 3500 | 8.2 | F | IP20 | 60min |
| ZC3-60 | 3 | 60 | 63 | 2000 | 14.33 | F | IP20 | 60min |
| ZC3-60 | 3 | 60 | 63 | 2800 | 10.2 | F | IP20 | 60min |
| ZC3-60 | 3 | 60 | 63 | 3500 | 8.2 | F | IP20 | 60min |
| ZC3-72 | 3 | 72 | 52 | 3500 | 8.2 | F | IP20 | 60min |
| ZC3.5-48 | 3.5 | 48 | 91 | 2800 | 11.9 | F | IP20 | 60min |
| ZC3.5-60 | 3.5 | 60 | 73 | 2800 | 11.9 | F | IP20 | 60min |
| ZC3.5-72 | 3.5 | 72 | 61 | 2800 | 11.9 | F | IP20 | 60min |
| ZC4-48 | 4 | 48 | 104 | 1500 | 25.5 | F | IP20 | 60min |
| ZC4-48 | 4 | 48 | 104 | 2000 | 19.1 | F | IP20 | 60min |
| ZC4-48 | 4 | 48 | 104 | 2500 | 15.3 | F | IP20 | 60min |
| ZC4-48 | 4 | 48 | 104 | 2800 | 13.6 | F | IP20 | 60min |
| ZC4-48 | 4 | 48 | 104 | 3200 | 11.9 | F | IP20 | 60min |
| ZC4-48 | 4 | 48 | 104 | 3500 | 10.9 | F | IP20 | 60min |
| ZC4-60 | 4 | 60 | 83 | 2800 | 13.6 | F | IP20 | 60min |
| ZC4-60 | 4 | 60 | 83 | 2500 | 15.2 | F | IP20 | 60min |
| ZC4-72 | 4 | 72 | 69 | 2800 | 13.6 | F | IP20 | 60min |
| 他励型： | ||||||||
|
Model
|
Rated power | Rated voltage | Rated current | Rated speed | Rated torque | Insultation | Protect | Working |
| （Kw） | (V) | (A) | (r/min) | (N.m) | ||||
| ZT1.5-36 | 1.5 | 36 | 55 | 2800 | 5.1 | F | IP20 | 60min |
| ZT1.5-48 | 1.5 | 48 | 42 | 2800 | 5.1 | F | IP20 | 60min |
| ZT2.2-36 | 2.2 | 36 | 76 | 2000 | 10.5 | F | IP20 | 60min |
| ZT2.2-36 | 2.2 | 36 | 76 | 2800 | 7.5 | F | IP20 | 60min |
| ZT2.2-48 | 2.2 | 48 | 57 | 1500 | 14 | F | IP20 | 60min |
| ZT2.2-48 | 2.2 | 48 | 57 | 2000 | 10.5 | F | IP20 | 60min |
| ZT2.2-48 | 2.2 | 48 | 57 | 2500 | 8.4 | F | IP20 | 60min |
| ZT2.2-48 | 2.2 | 48 | 57 | 2800 | 7.5 | F | IP20 | 60min |
| ZT2.2-60 | 2.2 | 60 | 46 | 3300 | 6.4 | F | IP20 | 60min |
| ZT3-36 | 3 | 36 | 104 | 1500 | 19 | F | IP20 | 60min |
| ZT3-36 | 3 | 36 | 104 | 2000 | 14.3 | F | IP20 | 60min |
| ZT3-36 | 3 | 36 | 104 | 2800 | 10.2 | F | IP20 | 60min |
| ZT3-48 | 3 | 48 | 78 | 1500 | 19.1 | F | IP20 | 60min |
| ZT3-48 | 3 | 48 | 78 | 2000 | 14.33 | F | IP20 | 60min |
| ZT3-48 | 3 | 48 | 78 | 2500 | 11.5 | F | IP20 | 60min |
| ZT3-48 | 3 | 48 | 78 | 2800 | 10.2 | F | IP20 | 60min |
| ZT3-48 | 3 | 48 | 78 | 3200 | 9 | F | IP20 | 60min |
| ZT3-48 | 3 | 48 | 78 | 3500 | 8.2 | F | IP20 | 60min |
| ZT3-60 | 3 | 60 | 63 | 2000 | 14.33 | F | IP20 | 60min |
| ZT3-60 | 3 | 60 | 63 | 2800 | 10.2 | F | IP20 | 60min |
| ZT3-60 | 3 | 60 | 63 | 3500 | 8.2 | F | IP20 | 60min |
| ZT3-72 | 3 | 72 | 52 | 3500 | 8.2 | F | IP20 | 60min |
| ZT3.5-48 | 3.5 | 48 | 91 | 2800 | 11.9 | F | IP20 | 60min |
| ZT3.5-60 | 3.5 | 60 | 73 | 2800 | 11.9 | F | IP20 | 60min |
| ZT3.5-72 | 3.5 | 72 | 61 | 2800 | 11.9 | F | IP20 | 60min |
| ZT4-48 | 4 | 48 | 104 | 1500 | 25.5 | F | IP20 | 60min |
| ZT4-48 | 4 | 48 | 104 | 2000 | 19.1 | F | IP20 | 60min |
| ZT4-48 | 4 | 48 | 104 | 2500 | 15.3 | F | IP20 | 60min |
| ZT4-48 | 4 | 48 | 104 | 2800 | 13.6 | F | IP20 | 60min |
| ZT4-48 | 4 | 48 | 104 | 3200 | 11.9 | F | IP20 | 60min |
| ZT4-48 | 4 | 48 | 104 | 3500 | 10.9 | F | IP20 | 60min |
| ZT4-60 | 4 | 60 | 83 | 2800 | 13.6 | F | IP20 | 60min |
| ZT4-60 | 4 | 60 | 83 | 2500 | 15.2 | F | IP20 | 60min |
| ZT4-72 | 4 | 72 | 69 | 2800 | 13.6 | F | IP20 | 60min |
