Description
Ratedpower: 60KW
Rated speed:1800r
Rated torque: 318N.m
Rated voltage:380V
Rated current:169A
Peakcurrent: 486A
Peaktorque: 640N.m
Maximum speed: 4500r
Weight: 158kg
Application:bus Note: Accordingto the needs, design the rated voltage range: 108-380V, the rated speed range:
1800r-5000r/min, the maximum speed: 9000r/min
